Specifications |
Standards |
AWS A5.14 ERNiCr-3, AWS A5.11 ENiCrFe-3 |
International Specifications |
BS 3072-3076 (NA14) DIN 17742, DIN 17750, DIN 17754 WERKSTOFF Nr 1.4301 TÜV 305 AFNOR-NC 15 Fe |
Length (mm): |
300 mm to 450 mm |
Diameter (mm): |
2.0 – 6.4 |
AWS Classification |
E308-16, E309-16, E316-16, E347-16, E2209-16 |
Type of Current |
2.0mm ∞ 5.0mm |
Polarity |
DC |
Size |
AC DC(+) |
Stainless steel |
ASTM / ASME SA 182 F 304 , 304L , 304H, 309H, 310H , 316 , 316H , 316L , 316 LN , 317 , 317L , 321 , 321H , 347 , 347 H ASTM / ASME A105 / ASTM / ASME A 350 LF 2 . |
Carbon Steel |
A36, 1045, 1018, 4140, 1095, 5160, A992, A500, A515, A516, A53, A106, A2, D2, SA-210, SA-192, A513, A105, 1075 |
Alloy Steel |
AISI 4130, AISI 4140, AISI 4340, AISI 8620, AISI 52100, AISI 6150, AISI 4145, ASTM A387, ASTM A514, ASTM A572, ASTM A588, ASTM A193, ASTM A519, SAE 8620, SAE 9310, SAE 6150 |
High Nickel Alloys Steel |
ASTM / ASME SB 564 UNS 2200 (Nickel 200), ASTM / ASME SB 564 UNS 4400 (Monel 400), ASTM / ASME SB 564 UNS 8825 (Inconel 825), ASTM / ASME SB 564 UNS 6600 (Inconel 600), ASTM / ASME SB 564 UNS 6601 (Inconel 601), ASTM / ASME SB 564 UNS 6625 (Inconel 625), ASTM / ASME SB 564 UNS 10276 (Hastelloy C-276), ASTM / ASME SB 160 UNS 2201 (Nickel 201), ASTM / ASME SB 472 UNS 8020 (Alloy 20 / 20 CB 3) |
Non Ferrous Metal |
A1000 Series, 2000 Series, 3000 Series, 5000 Series, C10100, C11000, C26000, 260 Brass, 360 Brass, 630 Bronze, C51000, Monel 400, AZ31, Zirconium 702 |
Duplex steel |
ASTM / ASME SA 182 F 44 , F 45 , F51 , F 53 , F 55 , F 60 , F 61. |
Alloy steel |
ASTM / ASME A 182 GR F 5, F 9 , F 11 , F 12 , F 22 , F 91. |
